iRig Mic Video Specifications
- Microphone Type: condenser, electret
- Capsule Size: 0.55”
- Polar Pattern: Supercardioid
- Interface Type: USB digital shotgun microphone with built-in preamp
- Conversion: 24-bit A/D, 24-bit D/A
- Sampling Rate: 44.1 kHz, 48 kHz, 88.2 kHz and 96 kHz
- Frequency Response: 20Hz - 20kHz
- Maximum Sound Pressure: 125 dB
- Sensitivity: -40 dB, 10 mV/Pa
- Gain: adjustable over a 47 dB range
- Controls: gain thumbwheel and direct monitor button
- Metering: Built-in multicolor LED for status and audio level indication
- Connector Type: Micro-USB
- Headphones output: 1/8” TRS jack
- DSLR camera output: 1/8” TRS jack
- Power: USB powered. Battery powered (3V CR1632, not included) for DSLR operations.
- Battery duration: over 50 hours use
Package includes
- iRig Mic Video microphone
- Lightning to micro-USB connection cable (16cm/6.3")
- USB C-Type to micro-USB connection cable (30cm/11.81")
- micro-USB OTG-Type to micro-USB connection cable (16cm/6.3")
- TRS 1/8" jack connection cable for digital cameras
- Hot shoe mount for digital cameras
- Windshield
- 2x ferromagnetic plates
Dimensions
- Size: 45mm/1.77" x 130mm/5.12" x 55mm/2.17"
- Weight: 65g/2.29oz
Compatibility
iOS Devices
Compatible with iPhone XS Max, iPhone XS, iPhone XR, iPhone X, iPhone 8 Plus, iPhone 8, iPhone 7 Plus, iPhone 7, iPhone SE, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6, iPhone 5s, iPhone 5c, iPhone 5, iPad Pro 10.5-inch, iPad Pro 12.9-inch (2nd generation), iPad Pro 9.7-inch, iPad Pro 12.9-inch (1st generation), iPad mini 4, iPad Air 2, iPad mini 3, iPad Air, iPad mini 2, iPad mini, iPad (6th generation), iPad (5th generation), iPad (4th generation), iPod touch (6th generation), iPod touch (5th generation). iOS 6 or later is required.
Also compatible with all newer iPhone, iPad and iPod touch models.
Computers
Mac®: macOS® 10.6 or later. One free USB port.
Windows®: One free USB port. For low latency, the IK Multimedia's iRig audio driver must be installed.
